std::execution: Inclusive Scan

Inclusive scan solves problems related to range queries, such as calculating the sum of a range of elements in an array. It is also used in range minimum queries and various other algorithms.

Before I present the asynchronous inclusive scan, I introduce the inclusive scan, aka prefix sum.

Prefix Sum

In computer science, the prefix sum, cumulative sum, inclusive scan, or simply scan of a sequence of numbers x₀, x₁, x₂, … is a second sequence of numbers y₀, y₁, y₂, …, the sums of prefixes (running totals) of the input sequence:

    y0 = x0
    y1 = x0 + x1
    y2 = x0 + x1+ x2
    ...

(https://en.wikipedia.org/wiki/Prefix_sum)

Proposal P2300R10 has an asynchronous implementation of inclusive scan.

Asynchronous Inclusive Scan

using namespace std::execution;

sender auto async_inclusive_scan(scheduler auto sch,                          // 2
                                 std::span<const double> input,               // 1
                                 std::span<double> output,                    // 1
                                 double init,                                 // 1
                                 std::size_t tile_count)                      // 3
{
  std::size_t const tile_size = (input.size() + tile_count - 1) / tile_count;

  std::vector<double> partials(tile_count + 1);                               // 4
  partials[0] = init;                                                         // 4

  return just(std::move(partials))                                            // 5
       | continues_on(sch)
       | bulk(tile_count,                                                     // 6
           [ = ](std::size_t i, std::vector<double>& partials) {              // 7
             auto start = i * tile_size;                                      // 8
             auto end   = std::min(input.size(), (i + 1) * tile_size);        // 8
             partials[i + 1] = *--std::inclusive_scan(begin(input) + start,   // 9
                                                      begin(input) + end,     // 9
                                                      begin(output) + start); // 9
           })                                                                 // 10
       | then(                                                                // 11
           [](std::vector<double>&& partials) {
             std::inclusive_scan(begin(partials), end(partials),              // 12
                                 begin(partials));                            // 12
             return std::move(partials);                                      // 13
           })
       | bulk(tile_count,                                                     // 14
           [ = ](std::size_t i, std::vector<double>& partials) {              // 14
             auto start = i * tile_size;                                      // 14
             auto end   = std::min(input.size(), (i + 1) * tile_size);        // 14
             std::for_each(begin(output) + start, begin(output) + end,        // 14
               [&] (double& e) { e = partials[i] + e; }                       // 14
             );
           })
       | then(                                                                // 15
           [ = ](std::vector<double>&& partials) {                            // 15
             return output;                                                   // 15
           });                                                                // 15
}

Here’s the explanation from the proposal P2300R10:

It scans a sequence of doubles (represented as the std::span<const double> input) and stores the result in another sequence of doubles (represented as std::span<double> output).
It takes a scheduler, which specifies what execution resource the scan should be launched on.
It also takes a tile_count parameter that controls the number of execution agents that will be spawned.
First we need to allocate temporary storage needed for the algorithm, which we’ll do with a std::vector, partials. We need one double of temporary storage for each execution agent we create.
Next we’ll create our initial sender with execution::just and execution::continues_on. These senders will send the temporary storage, which we’ve moved into the sender. The sender has a completion scheduler of sch, which means the next item in the chain will use sch.
Senders and sender adaptors support composition via operator|, similar to C++ ranges. We’ll use operator| to attach the next piece of work, which will spawn tile_count execution agents using execution::bulks.
Each agent will call a std::invocable, passing it two arguments. The first is the agent’s index (i) in the execution::bulk operation, in this case a unique integer in [0, tile_count). The second argument is what the input sender sent – the temporary storage.
We start by computing the start and end of the range of input and output elements that this agent is responsible for, based on our agent index.
Then we do a sequential std::inclusive_scan over our elements. We store the scan result for our last element, which is the sum of all of our elements, in our temporary storage partials.
After all computation in that initial bulk pass has completed, every one of the spawned execution agents will have written the sum of its elements into its slot in partials.
Now we need to scan all of the values in partials. We’ll do that with a single execution agent which will execute after the execution::bulk completes. We create that execution agent with execution::then.
execution::then takes an input sender and an std::invocable and calls the std::invocable with the value sent by the input sender. Inside our std::invocable, we call std::inclusive_scan on partials, which the input senders will send to us.
Then we return partials, which the next phase will need.
Finally we do another execution::bulk of the same shape as before. In this execution::bulk, we will use the scanned values in partials to integrate the sums from other tiles into our elements, completing the inclusive scan.
async_inclusive_scan returns a sender that sends the output std::span<double>. A consumer of the algorithm can chain additional work that uses the scan result. At the point at which async_inclusive_scan returns, the computation may not have completed. In fact, it may not have even started.

Sender

bulk(input, shape, call): Returns a sender which describes the callable call invoked on input according to shape.
continues_on(input, scheduler): Returns a sender describing the transition from the execution agent of the input sender to the execution agent of the target scheduler.
just(values): Returns a sender with no completion schedulers, which sends the provided values. just is a sender factory.
then(input, call): then returns a sender describing the continuation of the task of the input sender on an added node of invoking the provided function call.

Would it not be nice to see this program in action? Currently (December 2024), no compiler supports std::execution or the concepts sender and scheduler.

Here comes the reference implementation stdexec to our rescue:

I changed the data type of the processed elements from double to int.

Modernes C++ Mentoring

"Fundamentals for C++ Professionals" (open)

"Design Patterns and Architectural Patterns with C++" (open)

"C++20: Get the Details" (open)

"Concurrency with Modern C++" (open)

"Generic Programming (Templates) with C++": October 2024

"Embedded Programming with Modern C++": October 2024

"Clean Code: Best Practices for Modern C++": March 2025

Do you want to stay informed: Subscribe.

// inclusiveScanExecution.cpp

#include <algorithm>
#include <exec/static_thread_pool.hpp>
#include <iostream>
#include <numeric>
#include <span>
#include <stdexec/execution.hpp>
#include <vector>

auto async_inclusive_scan(auto sch,                   // 2
                          std::span<const int> input, // 1
                          std::span<int> output,      // 1
                          int init,                   // 1
                          std::size_t tile_count)     // 3
{
  std::size_t const tile_size = (input.size() + tile_count - 1) / tile_count;

  std::vector<int> partials(tile_count + 1); // 4
  partials[0] = init;                        // 4

  return stdexec::just(std::move(partials)) // 5
         | stdexec::continues_on(sch) |
         stdexec::bulk(tile_count,                                      // 6
                       [=](std::size_t i, std::vector<int> &partials) { // 7
                         auto start = i * tile_size;                    // 8
                         auto end =
                             std::min(input.size(), (i + 1) * tile_size); // 8
                         partials[i + 1] =
                             *--std::inclusive_scan(begin(input) + start,   // 9
                                                    begin(input) + end,     // 9
                                                    begin(output) + start); // 9
                       }) // 10
         | stdexec::then( // 11
               [](std::vector<int> &&partials) {
                 std::inclusive_scan(begin(partials), end(partials), // 12
                                     begin(partials));               // 12
                 return std::move(partials);                         // 13
               }) |
         stdexec::bulk(
             tile_count,                                                 // 14
             [=](std::size_t i, std::vector<int> &partials) {            // 14
               auto start = i * tile_size;                               // 14
               auto end = std::min(input.size(), (i + 1) * tile_size);   // 14
               std::for_each(begin(output) + start, begin(output) + end, // 14
                             [&](int &e) { e = partials[i] + e; }        // 14
               );
             }) |
         stdexec::then(                         // 15
             [=](std::vector<int> &&partials) { // 15
               return output;                   // 15
             });                                // 15
}

int main() {

  std::cout << '\n';

  std::vector<int> input(30);
  std::iota(begin(input), end(input), 0);
  for (auto e : input) {
    std::cout << e << ' ';
  }
  std::cout << '\n';

  std::vector<int> output(input.size());

  exec::static_thread_pool pool(8);
  auto sch = pool.get_scheduler();

  auto [out] =
      stdexec::sync_wait(async_inclusive_scan(sch, input, output, 0, 4))
          .value();

  for (auto e : out) {
    std::cout << e << ' ';
  }

  std::cout << '\n';
}

Here is an explanation of the main program:

In the main a std::vector<int> input is then created with 30 elements. The std::iota function fills the input vector with sequential integers starting from 0. The program then prints the contents of the input vector to the console.

Next, a std::vector<int> output is created with the same size as the input vector to store the results of the inclusive scan operation. The exec::static_thread_pool pool has 8 threads, which will be used to execute tasks concurrently. The get_scheduler member function of the thread pool creates a scheduler object sch.

The async_inclusive_scan function takes the scheduler sch, the input vector, the output vector, an initial value of 0, and a tile count of 4. This function performs the inclusive scan operation asynchronously using the specified scheduler and returns a future-like object. The stdexec::sync_wait function synchronously wait for the completion of the async_inclusive_scan operation, and the result is unpacked into the variable out.

Finally, the program prints the contents of the out vector to the console:

What’s Next?

In my next blog post, I will step one step back and explain the composition of senders via operator |.
